The Eaton Fuller Range Section Assembly, part number S-3236 or S3236, is a genuine Eaton Fuller manual transmission component covering the range section of the gearbox. The range section is the rear portion of a Fuller transmission responsible for the high/low range split, and replacing it as a complete assembly helps restore proper range engagement and shifting. Sold individually by Pro Gear and Transmission. Call us to confirm this assembly fits your specific transmission model and configuration.
Interchanges:
- S2783R
- Mack 3088-S2783R
What's in this assembly (13 parts)
| 1 x 14142 O-Ring | 1 x 14335 Case Gasket Rear Housing |
| 2 x 20815 Lifting Eye | 2 x 4301851 Auxiliary Countershaft Bearing |
| 2 x 4302320 Auxiliary Countershaft Cover | 2 x 4306402 Shipping Plug |
| 1 x 4306520 Hex Flange Crimped Nut | 2 x 4309436 Gasket Cover |
| 1 x 5568511 O-Ring | 1 x K-2805 Shim Kit |
| 1 x S-3232 Partial Auxiliary Section | 2 x X8C409 Hex Washer Screw Assembly |
| 8 x X-8L-604 Screw |
Features
Genuine Eaton Fuller range section assembly
Part number S-3236 or S3236
Direct replacement for Fuller high/low range section
Sold as a complete assembly, unit of measure: each
Available from Pro Gear and Transmission - call to confirm fit for your transmission
Tech Specs
- Part Number: S-3236 or S3236
- Unit of Measure: Each
- Component Type: Range Section Assembly
- NMFC Code: 121875 - Miscellaneous Truck Parts, including Transmission and Clutch Parts, Gears, Pumps
Used in these Eaton Fuller models
