The Eaton clutch assembly, part number 104200-1 or 1042001, is a diaphragm spring, adjustment-free clutch rated at 860 lb-ft torque with a 1.75-inch, 10-spline input configuration. Designed for vehicle drivetrain applications, this assembly eliminates manual adjustment, reducing maintenance time between service intervals. Sold individually. Call us to confirm proper fit for your specific truck application before ordering.
Interchanges:
- 1042001-SP
- CTD1042001
- EAT-104200-1
- N25
- NMU005-103-1-A
- FREIGHTLINER TRUCK PARTS SP104200-1
- MACK 2104-1042001
Features
Diaphragm spring design, adjustment-free operation
860 lb-ft torque rating
1.75 in. diameter, 10-spline input configuration
Sold as a single assembly (each)
Genuine Eaton part, available from Pro Gear and Transmission
Tech Specs
- Part Number: 104200-1 (also 1042001)
- Type: Diaphragm Spring, Adjustment-Free Clutch Assembly
- Torque Rating: 860 lb-ft
- Input: 1.75 in. diameter, 10 splines
- Sold As: Each
