Fabco plug 758-0386 is a metal plug cut 3/4-16 UNF, a straight thread, with an O-ring to seal it. The TC 180 transfer case parts manual carries it at item 87B under figure 14, remaining parts, one per assembly, and the drawing shows it threaded into a pad on the side of the finished case housing. Two other ports share that pad in the same figure, one taking the sight glass plug and the lower one the magnetic plug, so it is worth checking which hole you are looking at before you order. Genuine Fabco part from Pro Gear and Transmission.
Features
Metal plug with O-ring
3/4-16 UNF straight thread
Item 87B, figure 14 remaining parts, Fabco TC 180 transfer case
One per assembly
Drawn threaded into a pad on the side of the finished case housing
Genuine Fabco part from Pro Gear and Transmission
Tech Specs
- Part type: Plug with O-ring, metal
- Thread: 3/4-16 UNF
- Parts list reference: item 87B, figure 14, Fabco TC 180 transfer case
- Quantity: 1 per assembly
- UPC: 193174423567
Used in these Fabco Transfer Case model
