Fabco part 724-0625 or 7240625 is a cap screw with a 5/8-11 UNC thread and a 1-1/4 in. grip length, fitted with a 12-point flanged head. The 12-point drive pattern allows higher torque application in tight spaces where a standard hex socket cannot fully seat, and the integral flange distributes clamping load without a separate washer. This fastener is sourced directly from Fabco for use in Fabco transfer cases, steerable drive axles, and PTO assemblies. Pro Gear and Transmission carries genuine Fabco hardware. Call us to confirm this is the correct fastener for your specific assembly.
Features
Fabco part number 724-0625 or 7240625
5/8-11 UNC thread size
1-1/4 in. body length
12-point flanged head design
Integral flange eliminates need for a separate washer
Suitable for Fabco transfer case, steerable drive axle, and PTO assemblies
Tech Specs
- Thread Size: 5/8-11 UNC
- Length: 1-1/4 in.
- Head Style: 12-Point Flanged Cap Screw
- Brand: Fabco
- Part Number: 724-0625 or 7240625
