The Meritor A1-3260F1826 (also listed as A13260F1826) is a 170N Series end yoke for heavy-duty driveline applications. It features 46 internal splines on a 2.390 in. spline diameter with a spline length of 2.32 in. and a hub diameter of 3.25 in. The center-to-end measurement is 5.10 in., distance between nibs is 6.46 in., and the bearing cap diameter is 2.17 in. Counter bore depth is 0.14 in. Compatible U-joint kit is US170X; service kit is KIT-US250-170X. Deflector DEFR56-12 is specified for this yoke. Interchange references include 8235A13260F1826 and TDAA13260F1826. A genuine Meritor part sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Meritor 170N Series end yoke, part number A1-3260F1826 or A13260F1826
46 internal splines, 2.390 in. spline diameter, 2.32 in. spline length
Hub diameter: 3.25 in.; bearing cap diameter: 2.17 in.
Center-to-end: 5.10 in.; distance between nibs: 6.46 in.; counter bore depth: 0.14 in.
Compatible U-joint kit: US170X; service kit: KIT-US250-170X
Specified deflector: DEFR56-12; interchanges with 8235A13260F1826 and TDAA13260F1826
Tech Specs
- Number of Splines: 46 (internal)
- Series: 170N
- Spline Diameter: 2.390 in.
- Hub Diameter: 3.25 in.
- Spline Length: 2.32 in.
- Center To End: 5.10 in.
- Counter Bore Depth: 0.14 in.
- Bearing Cap Diameter: 2.17 in.
- Distance Between Nibs: 6.46 in.
- Deflector: DEFR56-12
- Use U-Joint Kit: US170X
- Use Kit: KIT-US250-170X
- VMRS Code: 024-002-048
