MMD1369DD is a Meritor pad kit for the ADB22X twin piston air disc brake caliper, with MA9500 lining in a refuse mix for severe service. The kit carries FMSI 1369 and a backing plate 8 1/4 in. wide and 4 1/4 in. high. The lining is a low resin formula made with a positive mold process, with moderate torque and good wear features. On an air disc brake the pads press against the rotor to slow the wheel and the lining is the wear item, so a quick look at the caliper wear indicator tells you how much lining is left. Call us to confirm proper fit before you order.
Features
For the ADB22X twin piston air disc brake caliper
MA9500 lining, refuse mix
Severe service and refuse applications
FMSI 1369
Backing plate 8 1/4 in. wide by 4 1/4 in. high
Low resin formula, positive mold process, moderate torque, good wear features
Tech Specs
- Marketing Group:8 1/4" Width Bendix ADB22X
- Lining Type:MA9500
- Application:Severe Service, All Applications, Refuse
- FMSI:1369
- Backing Plate Height:4 1/4 in.
- Genuine/Aftermarket:Aftermarket
- Copper Compliance Level:N
- Backing Plate Width:8 1/4 in.
- OEM:Knorr- Bremse (Bendix)
- Features:Low Resin Formula; Positive mold process; Moderate Torque; Good Wear Features
- Model:ADB22X
- Type:ADB
- Caliper Type:Twin Piston
