Meritor FS9069 is a genuine Meritor air spring of the reversible sleeve type, with a stud mount on the bottom and a flat mount on top. It collapses to 7.50 in. and extends to a maximum height of 18.00 in., with a part diameter of 10.12 in., a piston height of 4.75 in., and bead plate diameters of 9.50 in. at the bottom and 9.00 in. at the top. It is listed for Peterbilt applications. An air spring is a pressurized rubber bag that carries load and soaks up road shock. When one leaks from a puncture, dry rot or age, the vehicle leans, sags at a corner, or makes the compressor cycle more often than normal. Call us to confirm proper fit for your application.
Features
Reversible sleeve air spring design
Collapsed height 7.50 in., maximum height 18.00 in.
Part diameter 10.12 in., piston height 4.75 in.
Bead plate diameter 9.50 in. bottom, 9.00 in. top
Stud mount on the bottom, flat mount on top
A leaking bag shows up as leaning, a sagging corner or extra compressor cycling
Tech Specs
- Air Spring Type: Reversible Sleeve
- Collapsed Height: 7.50 in
- Maximum Height: 18.00 in
- Part Diameter: 10.12 in
- Piston Height: 4.75 in
- Bead Plate Diameter Bottom: 9.50 in
- Bead Plate Diameter Top: 9.00 in
- Stud Configuration Bottom: 01
- Stud Configuration Top: 03
- Bottom Mount: Stud
- Top Mount: Flat
