The Meritor FS9320 is a genuine OEM air spring for heavy-duty truck suspension, designed as a reversible sleeve type with a 10.12 in. part diameter. It measures 9.70 in. collapsed and extends to a maximum height of 27.60 in., with a bottom bead plate diameter of 10.30 in. and a top bead plate diameter of 9.00 in. The piston height is 7.40 in. Stud configuration is 4-stud on the bottom flat mount and 2-stud on the top. This spring fits the Holland (Neway) 90557099 Silent Drive suspension. Call us to confirm proper fit for your suspension application.
Interchanges:
- Automann 566CT64382
- Automann AB1DK23N9320
- BWP M3558
- Contitech 91021P360
- Dayton Parts Batco 1R12363
- Dayton Parts Batco 3529320
- Firestone 9320
- Firestone W013589320
- Flagg 8360
- Flagg AS8360
- Goodyear 1R12663
- Neway 57009320
- Ridewell 1003589320C
Features
Reversible sleeve air spring design
Part diameter: 10.12 in.
Collapsed height: 9.70 in., maximum height: 27.60 in.
Bottom bead plate: 10.30 in. diameter, 4-stud flat mount; top bead plate: 9.00 in. diameter, 2-stud mount
Piston height: 7.40 in.
Fits Holland (Neway) 90557099 Silent Drive suspension
Tech Specs
- Air Spring Type: Reversible Sleeve
- Part Diameter: 10.12 in.
- Collapsed Height: 9.70 in.
- Max. Height: 27.60 in.
- Bead Plate Diameter - Bottom: 10.30 in.
- Bead Plate Diameter - Top: 9.00 in.
- Piston Height: 7.40 in.
- Stud Configuration - Bottom: 4-stud, flat mount
- Stud Configuration - Top: 2-stud, stud mount
- Application: Holland (Neway) 90557099 Silent Drive
- UPC: 767555008133
- VMRS Code: 016-008-000
