Meritor R309328 alignment shim is a bar pin shim used to set axle alignment on heavy-duty truck suspensions. This part is engineered to OEM specs and covers 1/8 in. and 1/4 in. shim thicknesses for correcting caster and axle position on Hendrickson-style suspension setups. Sold by Pro Gear and Transmission as a genuine Meritor part. Not sure this is your part? Give us a call to confirm proper fit for your suspension.
Interchanges:
- 8235R309328
- HD50131000
- HUD50131000
- TDAR309328
- Automann MHS108
- Dayton Parts Batco 334880
- Westar 20848
Features
Meritor bar pin alignment shim, part number R309328
1/8 in. and 1/4 in. shim thickness
Engineered to OEM specs for Hendrickson-style suspensions
Used to set axle caster and alignment
Tech Specs
- Type: Bar pin alignment shim
- Shim thickness: 1/8 in. and 1/4 in.
- Application: Hendrickson-style heavy-duty truck suspension
- OEM status: Engineered to OEM specs
