05-15861-003 Meritor Assembly - Front Hub / Abs

Meritor Assembly-Frt Hub/Abs P/N: 05-15861-003 or 0515861003. Genuine Meritor - Rockwell OEM brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake foot valves, and more. Genuine Meritor parts are just a click or call away.

Features

Axle Series:For GM
Tone Ring:Y
Hub Style:Conventional
Hub Type:Hub only
Axle Application:Steer
Fully Dressed:No
ABS Ring Number:09-002122
Base Part Number:15861
ABS Pilot Diameter:4.337/4.334 in.
Inner Cup:JM205110
Outer Cone:32207
Inner Cone:JM205149
Oil Seal:1205H2582
Outer Cup:32207
Wheel Stud Hole:.904/.906 in.
IBS to OBS:1.783/1.744 in.
Drum Bolt Pattern:10
Drum Bolt Size:.904/.906 in.
Wheel Stud Bolt Circle Diameter:11.25 in.
Drum Bolt Circle Diameter:11.25 in.
Hub Cap Pattern:06
Hub Cap Bolt Thread:5/16-18 UNC-2B
Wheel Stud Pattern:10
Hub Cap Bolt Circle Diameter:4.50 in.
Inner Bearing Surface (IBS) to Mounting Face:5.665 in.
IBS to Outer Surface:3.713/3.673 in.
GAWR (lb):8102
Brake Type:Drum
VMRS Code:018-001-003
Drum Pilot Diameter:8.778/8.775 in.
Flange Outer Diameter:13.00 in.
Wheel Pilot Diameter:8.653/8.646 in.
