Genuine Meritor Assembly-Frt Hub P/N: 05-15135-001 or 0515135001. This item is no longer available. Please call us for a replacement. Genuine Meritor parts are just a click or call away.
Tech Specs
- Tone Ring:N
- Axle Series:GM 8,085 lb axle 15 x 4 brake
- Fully Dressed:No
- Hub Style:Conventional
- Axle Application:Steer
- Hub Type:Hub only
- Base Part Number:15135
- Hub Cap Bolt Circle Diameter:4.50 in.
- Wheel Stud Pattern:10
- GAWR (lb):8102
- IBS to OBS:1.783/1.744 in.
- Wheel Stud Hole:.785/.787 in.
- IBS to Outer Surface:3.713/3.673 in.
- Oil Seal:1205H2582
- Outer Cup:32207
- Inner Cup:JM205110
- Inner Cone:JM205149
- Outer Cone:32207
- Inner Bearing Surface (IBS) to Mounting Face:5.666 in.
- Hub Cap Pattern:06
- Hub Cap Bolt Thread:M6 X 1.0-6H
- Wheel Stud Bolt Circle Diameter:11.25 in.
- Drum Bolt Circle Diameter:11.25 in.
- Drum Bolt Size:.785/.787 in.
- Drum Bolt Pattern:10
- Brake Type:Drum
- VMRS Code:018-001-003
- Drum Pilot Diameter:8.750/8.747 in.
- Flange Outer Diameter:13.00 in.
- Wheel Pilot Diameter:Stud
