15-16029-1001MTB Meritor Assembly Hub Drum

Meritor Assembly-Hub/Drum P/N: 15-16029-1001MTB or 15160291001MTB. Genuine Meritor - Rockwell OEM brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake foot valves, and more. Genuine Meritor parts are just a click or call away.

Non returnable item

Features

Axle Series:FL
Axle Application:Steer
Hub Style:Conventional
Fully Dressed:No
Tone Ring:Y
Hub Type:Hub/Drum Assembly
ABS Ring Number:09-002134
Base Part Number:16029
Hub Cap Pattern:06
IBS to Outer Surface:4.851/4.831 in.
Wheel Stud Pattern:10
Drum Bolt Circle Diameter:11.25 in.
Drum Bolt Pattern:10
IBS to OBS:3.041/3.021 in.
Hub Cap Bolt Circle Diameter:5.50 in.
Inner Bearing Surface (IBS) to Mounting Face:4.415 in.
ABS Pilot Diameter:6.302/6.299 in.
Outer Cone:555S
Inner Cone:6461A
Drum Bolt Size:.904/.906 in.
Wheel Stud Hole:.904/.906 in.
GAWR (lb):22000
Oil Seal:A1205M1339; A1205S2307
Outer Cup:552A
Inner Cup:6420
Wheel Stud Bolt Circle Diameter:13.189 in.
Hub Cap Bolt Thread:5/16-18 UNC-2B
Brake Type:Drum
VMRS Code:018-004-034
Notes:Machine to Balance brake drum
Drum Pilot Diameter:11.250/11.247 in.
Drum Number:85-123664-002
Flange Outer Diameter:14.675 in.
Wheel Pilot Diameter:11.055/11.048 in.
Wheel Stud:09-001888
