14-16062-1000MTB Meritor Assembly Hub Drum Ltw

Meritor Assembly-Hub/Drum Ltw P/N: 14-16062-1000MTB or 14160621000MTB. Genuine Meritor - Rockwell OEM brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake foot valves, and more. Genuine Meritor parts are just a click or call away.

Features

Tone Ring:Y
Axle Series:R Long
ABS Ring Number:3237H1256
Base Part Number:16062
ABS Pilot Diameter:6.882/6.879 in.
Outer Cone:580
GAWR (lb):27000
Wheel Stud Hole:.904/.906 in.
Drum Bolt Size:.904/.906 in.
Inner Cup:592A
Wheel Stud Pattern:10
Inner Cone:594A
Inner Bearing Surface (IBS) to Mounting Face:1.19 in.
Oil Seal:A1205Q2487
Outer Cup:572
IBS to OBS:4.327/4.287 in.
Drum Bolt Pattern:10
Drum Bolt Circle Diameter:11.25 in.
Wheel Stud Bolt Circle Diameter:11.25 in.
IBS to Outer Surface:7.77/7.73 in.
Drum Position:Outboard
Brake Type:Drum
DriveStud Bolt Circle Dia:7.00 in.
Drive Stud Pattern:08
VMRS Code:018-004-034
Drive Stud Thread:5/8-11 UNC-3B
Drive Flange Stud:08-205740
Drum Pilot Diameter:8.778/8.775 in.
Drum Number:85-123207-002
Flange Outer Diameter:13.00 in.
Wheel Pilot Diameter:8.653/8.646 in.
Wheel Stud:09-001728
