Meritor Assembly-Hub/Rotor P/N: 16-16009-1001 or 16160091001. Genuine Meritor - Rockwell OEM brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake foot valves, and more. Genuine Meritor parts are just a click or call away.
Features
Axle Series:Coach S
Tone Ring:N
Base Part Number:16009
Inner Cone:6580
Oil Seal:A1205L1546
Outer Cup:653
GAWR (lb):29000
Wheel Stud Pattern:10
IBS to Outer Surface:7.055 in.
Wheel Stud Hole:.904/.906 in.
IBS to OBS:3.928/3.948 in.
Wheel Stud Bolt Circle Diameter:13.189 in.
Outer Cone:663
Inner Cup:6535
Inner Bearing Surface (IBS) to Mounting Face:1.327 in.
Disc Bolt Pattern:10
Disc Bolt Circle Diameter:9.823 in.
Brake Type:EX
Disc Bolt Size:.659/.679 in.
DriveStud Bolt Circle Dia:7.25 in.
Drive Stud Pattern:10
VMRS Code:018-002-062
Drive Stud Thread:9/16-12 UNC-2B
Drive Flange Stud:4-X-1612
Flange Outer Diameter:15.12 in.
Rotor Pilot Diameter:7.632/7.635 in.
Wheel Pilot Diameter:11.055/11.047 in.
Wheel Stud:09-002003
