Meritor Assembly - Hub / Stud P/N: 04-15975-001 or 0415975001

04-15975-001 Meritor Assembly - Hub / Stud

Meritor

Hydraulic Brake - Hub and Stud Assembly

Listing Price: $1,565.18
Sale Price: $1,007.19

This item qualifies for FREE shipping on orders over $295 and under 70 lbs

(No reviews yet) Write a Review
Product Code:
MER0415975001
UPC:
680502338094
Condition:
New
Availability:
Usually Ships in 3 to 5 Business Days
Adding to cart… The item has been added
Meritor 04-15975-001 or 0415975001 is a conventional hub and stud assembly for a Hino-series drive axle, supplied as a hub only with wheel studs and built for a disc brake. It has a wheel stud pattern of 8 on an 8.858 in. bolt circle, a 10.50 in. flange outer diameter and a GAWR of 12000 lb. On a hub like this the wheel studs are fitted to the hub and the wheel bearing runs inside it, so it carries the wheel and lets it turn. A worn hub bearing usually shows as a roaring or grinding noise from the wheel and as play when the wheel is rocked. A genuine Meritor part from Pro Gear and Transmission. Call us to confirm proper fit for your application.

Features

Hino axle series, drive axle application, conventional hub style
Hub only with wheel studs, wheel stud pattern of 8 on an 8.858 in. bolt circle
Disc brake type with a disc bolt pattern of 8 on a 7.75 in. bolt circle
Bearing set: inner cone JLM506849, outer cone 39590, inner cup JLM506810, outer cup 39520
Oil seal A1205V2674, GAWR 12000 lb, no tone ring
A grinding or roaring noise from the wheel, or play when it is rocked, points to a worn hub bearing

Tech Specs

  • Axle series: Hino
  • Axle application: Drive
  • Hub style: Conventional
  • Hub type: Hub only, with wheel studs
  • Fully dressed: No
  • Tone ring: No
  • Brake type: Disc
  • Wheel stud pattern: 8
  • Wheel stud bolt circle diameter: 8.858 in.
  • Wheel stud hole: .604/.606 in.
  • Wheel stud: 09-002222
  • Disc bolt pattern: 8
  • Disc bolt circle diameter: 7.75 in.
  • Disc bolt size: .540/.520 in.
  • Drum bolt pattern: 8
  • Drum position: Outboard
  • Drive stud pattern: 8
  • Drive stud thread: M12 X 1.75-6H
  • Drive stud bolt circle diameter: 4.331 in.
  • Flange outer diameter: 10.50 in.
  • Rotor pilot diameter: 6.123/6.126 in.
  • Wheel pilot diameter: 6.693/6.689 in.
  • Inner bearing surface (IBS) to mounting face: 1.162 in.
  • IBS to outer surface: 4.995/4.755 in.
  • IBS to OBS: 2.795/2.755 in.
  • Inner cone: JLM506849
  • Outer cone: 39590
  • Inner cup: JLM506810
  • Outer cup: 39520
  • Oil seal: A1205V2674
  • GAWR (lb): 12000
  • VMRS code: 018-002-001
!
