Meritor part number 05-15996-003 or 0515996003 is a conventional hub assembly for FH series steer axles, rated at 17,600 lb GAWR. This is a hub-only unit (not fully dressed) with an integrated ABS tone ring and drum brake configuration. Key bearing components are inner cone 6461A, inner cup 6420, outer cone 555S, and outer cup 552A. The flange outer diameter measures 14.67/14.66 in., wheel pilot diameter 11.055/11.047 in., drum pilot diameter 11.250/11.247 in., and ABS pilot diameter 6.302/6.299 in. The 10-stud wheel bolt circle is 13.189 in. with stud holes of .904/.906 in. Inner bearing surface to mounting face is 4.13 in. Compatible oil seals are A1205P1108 and A1205Z780. Call us to confirm proper fit for your application.
Features
FH series steer axle application, drum brake type, hub-only (not fully dressed)
GAWR: 17,600 lb
ABS tone ring included; ABS ring number 09-002134, ABS pilot diameter 6.302/6.299 in.
Flange outer diameter: 14.67/14.66 in.; wheel pilot diameter: 11.055/11.047 in.; drum pilot diameter: 11.250/11.247 in.
10-stud, 10-bolt drum bolt pattern; wheel and drum bolt circle diameter: 13.189 in.; stud hole diameter: .904/.906 in.
Hub cap bolt circle: 6.00 in., hub cap bolt thread: 3/8-16 UNC-2B, hub cap pattern: 06
Tech Specs
- Axle Series: FH
- Axle Application: Steer
- Brake Type: Drum
- Hub Style: Conventional
- Hub Type: Hub only
- Fully Dressed: No
- Tone Ring: Yes
- GAWR: 17,600 lb
- Base Part Number: 15996
- ABS Ring Number: 09-002134
- ABS Pilot Diameter: 6.302/6.299 in.
- Flange Outer Diameter: 14.67/14.66 in.
- Wheel Pilot Diameter: 11.055/11.047 in.
- Drum Pilot Diameter: 11.250/11.247 in.
- Wheel Stud Bolt Circle Diameter: 13.189 in.
- Drum Bolt Circle Diameter: 13.189 in.
- Wheel Stud Pattern: 10
- Drum Bolt Pattern: 10
- Wheel Stud Hole Diameter: .904/.906 in.
- Drum Bolt Size: .904/.906 in.
- Wheel Stud: 09-001727
- Hub Cap Bolt Circle Diameter: 6.00 in.
- Hub Cap Bolt Thread: 3/8-16 UNC-2B
- Hub Cap Pattern: 06
- Inner Bearing Surface (IBS) to Mounting Face: 4.13 in.
- IBS to Outer Bearing Surface (OBS): 2.345/2.325 in.
- IBS to Outer Surface: 4.13 in.
- Inner Cone: 6461A
- Inner Cup: 6420
- Outer Cone: 555S
- Outer Cup: 552A
- Oil Seal: A1205P1108; A1205Z780
- VMRS Code: 018-001-003
