04-15900-003 Meritor Assembly - Rear Hub

Meritor Assembly-Rear Hub P/N: 04-15900-003 or 0415900003. Genuine Meritor - Rockwell OEM brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake foot valves, and more. Genuine Meritor parts are just a click or call away.

Non returnable item

Features

Tone Ring:N
Axle Series:L
Fully Dressed:No
Hub Style:Conventional
Axle Application:Drive
Hub Type:Hub only
Base Part Number:15900
Drum Position:Outboard
Inner Bearing Surface (IBS) to Mounting Face:1.8 in.
Drum Bolt Pattern:10
Wheel Stud Pattern:10
GAWR (lb):21000
Wheel Stud Hole:.904/.906 in.
IBS to Outer Surface:7.335/7.295 in.
Wheel Stud Bolt Circle Diameter:11.25 in.
IBS to OBS:4.645/4.605 in.
Inner Cone:47686
Outer Cone:39590
Outer Cup:39520
Oil Seal:A1205W1349
Inner Cup:47620
Disc Bolt Pattern:10
Disc Bolt Circle Diameter:7.25 in.
Brake Type:Drum
Disc Bolt Size:9/16-12 UNC-2B
DriveStud Bolt Circle Dia:5.50 in.
Notes:With Wheel Studs
VMRS Code:018-002-001
Drive Stud Pattern:08
Drive Stud Thread:5/8-11 UNC-3B
Drive Flange Stud:08-007591
Flange Outer Diameter:13.40 in.
Wheel Pilot Diameter:8.654/8.646 in.
Wheel Stud:09-002048
