14-16013-1000MTB Meritor Assembly - Rear Hub / Drum

Meritor Assembly-Rear Hub/Drum P/N: 14-16013-1000MTB or 14160131000MTB. Genuine Meritor - Rockwell OEM brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake foot valves, and more. Genuine Meritor parts are just a click or call away.

Features

Tone Ring:Y
Axle Series:R Short
ABS Ring Number:3237H1256
Base Part Number:16013
Inner Cone:594A
Outer Cone:580
Inner Cup:592A
Wheel Stud Pattern:10
Drum Bolt Circle Diameter:11.25 in.
Wheel Stud Bolt Circle Diameter:11.25 in.
IBS to Outer Surface:6.91/6.89 in.
GAWR (lb):26000
ABS Pilot Diameter:6.882/6.879 in.
Drum Position:Outboard
Drum Bolt Size:.904/.906 in.
IBS to OBS:4.317/4.297 in.
Drum Bolt Pattern:10
Wheel Stud Hole:.904/.906 in.
Outer Cup:572
Inner Bearing Surface (IBS) to Mounting Face:1.31 in.
Oil Seal:A1205Q2487
Brake Type:Drum
DriveStud Bolt Circle Dia:7.00 in.
Drive Stud Pattern:08
VMRS Code:018-004-034
Drive Stud Thread:5/8-11 UNC-3B
Drive Flange Stud:08-008551
Drum Pilot Diameter:8.778/8.775 in.
Drum Number:85-123466-002
Flange Outer Diameter:13.00 in.
Wheel Pilot Diameter:8.653/8.646 in.
Wheel Stud:09-002003
