Meritor brake shoe A1-3222L948 or A13222L948 is an unlined, front-axle shoe designed for drum brake assemblies using a 16.50 in. brake diameter and 5.00 in. shoe width. It carries FMSI number 4524 and lining designation R502 with Meritor Production lining type. The shoe features a relocated return spring and includes a roller. Rivet hole count is 16, with rivet number RV3109S and a rivet size of 0.25 in. Brake type is P. Compatible repair kits include R509000, R509001, R509002, R509011, R509015, and R509063. A genuine Meritor part, available from Pro Gear and Transmission. Call us to confirm fit for your specific axle configuration.
Features
Brake diameter: 16.50 in.
Brake shoe width: 5.00 in.
Front axle application with relocated return spring; roller included
FMSI: 4524 | Lining number: R502 | Brake type: P
Rivet holes: 16 | Rivet number: RV3109S | Rivet size: 0.25 in.
Compatible repair kits: R509000, R509001, R509002, R509011, R509015, R509063
Tech Specs
- Brake Diameter: 16.50 in.
- Brake Shoe Width: 5.00 in.
- Brake Type: P
- FMSI: 4524
- Lining Number: R502
- Lining Type: Meritor Production
- Friction Type: Unlined
- Application: Front axle, relocated return spring, includes roller
- Rivet Hole Count: 16
- Rivet Number: RV3109S
- Rivet Size: 0.25 in.
- Brake Shoe Repair Kits: R509000, R509001, R509002, R509011, R509015, R509063
- VMRS Code: 013-002-012
