R607376 Meritor left hand camshaft for a Q Plus trailer brake with a 16.50 in. brake diameter. It has 28 splines and an effective length of 8.875 in., head type 02, and 1.50 in. bushing journal and spline diameters. The shaft is gundrilled with an oil hole and 3 grooves. A brake camshaft turns the motion from the slack adjuster into the force that spreads the shoes against the drum, so play at the cam head or in its bushings shows up as uneven shoe wear and weaker stopping power. The matching right hand camshaft is R607377. A genuine Meritor part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Left hand camshaft with 28 splines and head type 02
Effective length 8.875 in.
Bushing journal 1.50 in. diameter by 1.50 in. long, spline diameter 1.50 in.
Gundrilled with an oil hole and 3 grooves
For Q Plus trailer brakes, 16.50 in. brake diameter
Matching right hand camshaft is R607377
Tech Specs
- Side: Left hand
- Effective length: 8.875 in.
- Spline count: 28
- Head type: 02
- Brake diameter: 16.50 in.
- Bushing journal diameter: 1.50 in.
- Bushing journal length: 1.50 in.
- Camshaft spline diameter: 1.50 in.
- Brake type: Q Plus
- Axle: Trailer
- Notes: Gundrilled, oil hole, 3 grooves
