The Meritor 2210V7536 is a right-hand S-cam camshaft for Q Plus drum brake assemblies on drive and steer axles. It measures 11.59 inches in effective length with a 1.50-inch diameter, 28-spline head end and a 1.77-inch bushing journal length. The head type is 11, designed for 16.50-inch brake diameter applications. The matched left-hand counterpart is Meritor 2210W7537. For camshaft reconditioning, the compatible repair kit is KIT8042; for brake hardware, KIT8000HD applies. A genuine Meritor part sold by Pro Gear and Transmission. Call us to confirm proper fit for your axle and brake configuration.
Interchanges:
- CAM199R
- CS41663
- CS9662R
- E3351
- EUE9662
- FX12228111804
- HR2210V7536
- L2338
- L3098
- MER2210V7536
- OTR9662
- PROWCQ313R
- RO2210V7536
- RW2210V7536
- S8454
- TA18832
- TCQ10313R
- TDA2210V7536
- TW04481151
- TWD2210V7536
- Automann 12228111804
- BWP M2614R
- Dana 18832
- Dayton Parts Batco 04481151
- Eaton Top Spec 72436
- Fleetrite FLTCS136
- Haldex 41663
- Hercules H10563R
- Hercules HQ10313R
- Spicer 18518
- Transit Parts TP8530
Features
Right-hand S-cam camshaft for Meritor Q Plus drum brake assemblies
Effective length: 11.59 in.; bushing journal length: 1.77 in.
Camshaft spline: 28-tooth, 1.50 in. diameter
Designed for 16.50 in. brake diameter applications
Fits drive and steer axle positions
Paired left-hand camshaft: Meritor 2210W7537; repair kit: KIT8042
Tech Specs
- Effective Length: 11.59 in.
- Bushing Journal Length: 1.77 in.
- Side: Right Hand (RH)
- Brake Diameter: 16.50 in.
- Camshaft Spline Diameter: 1.50 in.
- Camshaft Spline Count: 28
- Head Type: 11
- Brake Type: Q Plus
- Axle Position: Drive or Steer
- Paired Camshaft: Meritor 2210W7537
- Camshaft Repair Kit: KIT8042
- Brake Hardware Kit: KIT8000HD
- VMRS Code: 013-017-004
- OEM Manufacturer: Meritor
