The Meritor dust shield assembly, part number A1-3236Q2123 or A13236Q2123, is designed for use on 16-1/2 in. x 7 in. P and Q series drum brakes across multiple suspension models. It mounts via cap screw through 6 holes sized at 0.4375 in. and seats with a 10.125 in. inner diameter and an 18.125 in. outer diameter. The 1.50 in. offset positions the shield correctly relative to the drum face, and the 0.656 in. lip height provides the necessary debris coverage for the brake assembly. VMRS code 013-017-000. Sold by Pro Gear and Transmission as a genuine Meritor part. Call us to confirm proper fit for your specific axle and suspension configuration.
Features
Fits 16-1/2 in. x 7 in. P and Q series drum brakes across multiple suspension models
6 mounting holes, cap screw mount, hole size 0.4375 in.
Outer diameter: 18.125 in. | Inner diameter: 10.125 in.
Offset: 1.50 in. | Lip height: 0.656 in.
Brake diameter: 16.50 in. | Brake shoe width: 7.00 in.
VMRS code: 013-017-000
Tech Specs
- Brake Size: 16.50 in. x 7.00 in.
- Brake Model: P and Q Series
- Outer Diameter: 18.125 in.
- Inner Diameter: 10.125 in.
- Offset: 1.50 in.
- Lip Height: 0.656 in.
- Number of Mounting Holes: 6
- Hole Size: 0.4375 in.
- Mount Type: Cap Screw
- Suspension Model: Multiple
- VMRS Code: 013-017-000
