The Meritor G9570 (also listed as G-9570) is a fabricated equalizer designed for Hutchens Four Spring Suspension systems, specifically the H/CH 7700 and 9700 series with 42-1/2, 44, 49, and 50 axle spacing configurations. This light-duty equalizer measures 16.50 in. in length with a center-to-center dimension of 11.75 in. and features a 0.75 in. shaft O.D. with a matching bushing I.D. The 3.25 in. inside diameter rubber bushing is included, and the part has 2 mounting holes. It crosses to OEM part number 750-03 (Hutchens). Related bushing is G-1999A. Call us to confirm proper fit for your specific suspension configuration.
Features
Fits Hutchens Four Spring Suspension H/CH 7700 and 9700 series, 42-1/2, 44, 49, and 50 axle spacing
Fabricated construction, light-duty rating
16.50 in. overall length; 11.75 in. center-to-center
0.75 in. shaft O.D. and bushing I.D.
3.25 in. bushing inside diameter, rubber bushing type, included with part
Crosses to Hutchens OEM part 750-03; related bushing G-1999A
Tech Specs
- Bushing Included: Yes
- Number of Holes: 2
- Length: 16.50 in.
- Center to Center: 11.75 in.
- Shaft O.D. and Bushing I.D.: 0.75 in.
- Bushing Inside Diameter: 3.25 in.
- Bushing Type: Rubber
- Construction: Fabricated
- Axle Spacing: 49.00 in.
- Model Fitment: Hutchens Four Spring Suspension H/CH 7700/9700, 42-1/2 44 49 50 Axle Spacing
- OE Manufacturer: Hutchens
- OEM Part Number: 750-03
- Related Bushing: G-1999A
- Duty Rating: Light Duty
