The Meritor flange yoke 131N2-329 or 131N2329 is a Series 131N driveline flange yoke built to Meritor's heavy-duty driveline standards. The flange measures 3.88 in. outside diameter with a 3.13 in. bolt circle, four drilled bolt holes at 0.38 in. diameter, and a 2.38 in. pilot diameter (Pilot Type M). The yoke spans 3.47 in. across the ears, with a 1.06 in. bearing cap diameter and a 1.38 in. center-to-face dimension. It supports a 20-degree joint angle and is compatible with Meritor u-joint kits CP153X or CP200X. VMRS Code: 024-001-003. Call us to confirm proper fit for your specific driveline configuration. A genuine Meritor part from Pro Gear and Transmission.
Features
Series 131N Meritor flange yoke, part number 131N2-329 or 131N2329
Flange outside diameter: 3.88 in.; bolt circle diameter: 3.13 in.
Four drilled bolt holes, 0.38 in. diameter each
Pilot diameter: 2.38 in., Pilot Type M; center-to-face: 1.38 in.
20-degree joint angle; bearing cap diameter: 1.06 in.
Compatible u-joint kits: CP153X or CP200X
Tech Specs
- Series: 131N
- Flange Outside Diameter: 3.88 in.
- Bolt Circle Diameter: 3.13 in.
- Bolt Hole Diameter: 0.38 in.
- Bolt Holes: 4, Drilled
- Pilot Diameter: 2.38 in.
- Pilot Type: M
- Yoke Dimension Across Ears: 3.47 in.
- Center To Face: 1.38 in.
- Joint Angle: 20 degrees
- Bearing Cap Diameter: 1.06 in.
- Compatible U-Joint Kits: CP153X or CP200X
- VMRS Code: 024-001-003
