Features
Axle Series: TN/TQ
Tone Ring:Y
Fully Dressed: No
Hub Type: Hub only
Axle Application: Trailer
Hub Style: Preset
ABS Ring Number:R930201
Base Part Number:16048
Inner Bearing Surface (IBS) to Mounting Face:0.28 in.
Wheel Stud Pattern:10
GAWR (lb):23000
Drum Bolt Pattern:10
Wheel Stud Hole:.904/.906 in.
Drum Bolt Size:.904/.906 in.
IBS to Outer Surface:4.747/4.727 in.
ABS Pilot Diameter:6.503/6.50 in.
Inner Cup:HM218210
Drum Position: Outboard
Outer Cone:HM212049
Oil Seal:A1205X1662
Outer Cup:HM212011
Hub Cap Bolt Thread:5/16-18 UNC-2B
Hub Cap Bolt Circle Diameter:5.50 in.
Inner Cone:HM218248
IBS to OBS:3.348/3.344 in.
Drum Bolt Circle Diameter:11.25 in.
Wheel Stud Bolt Circle Diameter:11.25 in.
Hub Cap Pattern:06
Brake Type: Drum
VMRS Code:018-004-030
Notes:Conmet 10012143
Drum Pilot Diameter:8.778/8.774 in.
Flange Outer Diameter:12.825 in.
Wheel Pilot Diameter:8.653/8.649 in.
Wheel Stud:R930190
