The Meritor E-2769HD or E2769HD is a Mega Plus repair kit for Q and Q Plus Double Anchor Pin Quick Change brake shoes on 16.50-inch drum brakes. It covers drive axle and trailer axle applications across Meritor Q and Q Plus, Spicer (Dana) Fast Change and XLII, and Hendrickson Intraax brake systems. The kit features stainless steel bushings and includes a Posi-Plus roller. Compatible brake shoe widths span 5.00 in., 6.00 in., 7.00 in., 8.00 in., 8.625 in., and 10.00 in. FMSI numbers covered: 4524Q, 4718QP, 4711QP, 4515Q, 4514Q, 4707QP, and 4551Q. This kit also crosses to multiple Dayton/Batco, Dana/Spicer, Haldex, Trailmobile, Hendrickson, Dexter, Fruehauf, and World American part numbers. Call us to confirm proper fit for your application.
Features
Mega Plus kit for Meritor Q and Q Plus Double Anchor Pin Quick Change brake shoes
Brake diameter: 16.50 in.; fits shoe widths of 5.00, 6.00, 7.00, 8.00, 8.625, and 10.00 in.
Stainless steel bushing type with included Posi-Plus roller
Covers drive axle and trailer axle applications
Fits Meritor Q/Q Plus, Spicer (Dana) Fast Change and XLII, and Hendrickson Intraax brake systems
Replaces Dayton/Batco, Dana/Spicer, Haldex, Trailmobile, Hendrickson, Dexter, Fruehauf, and World American cross-references
Tech Specs
- Brake Type: Q and Q Plus
- FMSI: 4524Q, 4718QP, 4711QP, 4515Q, 4514Q, 4707QP, 4551Q
- Brake Diameter: 16.50 in.
- Brake Width: 5.00 in., 6.00 in., 7.00 in., 8.00 in., 8.625 in., 10.00 in.
- Kit Type: Mega Plus
- Bushing Type: Stainless Steel
- Application: Drive Axle, Trailer Axle
- OE Manufacturer: Meritor
- Parent Description: Q and Q Plus Double Anchor Pin Quick Change Brake Shoe
- Contains: Posi-Plus roller
- Compatible Brake Shoes: E-3303 (5.00 in.), E-3304 (6.00 in.)
- Cross-References - Dayton/Batco: 081088, 08108830, 08108831, 08108838, 08108865, 08108875, 081092, 081126, 081132
- Cross-References - Dana/Spicer: 28A, 29A, 64A, HK29, HK29BULK
- Cross-References - Trailmobile: 382769, 382769HD
- Cross-References - Haldex: CQ66867
- Cross-References - Dexter: K7113600
- Cross-References - Fruehauf: MRS008000
- Cross-References - Hendrickson: S23752
- Cross-References - World American Parts: WA8000HD
- Cross-References - Other: 8235KIT8000, 8235KIT8000A, 8235KIT8000HD, ETN53319, KIT8000, KIT8000BULK, KIT8000HD, KIT8000HDBULK, V1115871, ZDRKIT8000, ZZCQ66861, ZZCQ66867, 2769HDP, E2769BHD, K339
