Meritor M83127 is a standard heavy-duty shock absorber with a 178 mm (7.01 in) stroke, a collapsed length of 333.0 mm (13.11 in) and an extended length of 511 mm (20.12 in). The 50.8 mm (2.00 in) body has a 30 mm (1.18 in) bore and a 60 mm (2.36 in) dust shield, and the unit includes a hydraulic stop. It is engineered to OEM specs.
A shock damps spring movement so the vehicle settles after a bump instead of bouncing on. Fluid on the outside of the body, repeated bouncing or swaying, and clunks from the suspension area are signs a shock is due for replacement. A genuine Meritor part from Pro Gear and Transmission.
Features
Stroke: 178 mm (7.01 in)
Collapsed length 333.0 mm (13.11 in), extended length 511 mm (20.12 in)
Body diameter 50.8 mm (2.00 in) with a 30 mm (1.18 in) bore
60 mm (2.36 in) dust shield and hydraulic stop
Standard heavy-duty type, engineered to OEM specs
Damps spring movement so the vehicle settles after bumps instead of bouncing on
Tech Specs
- Type: Standard
- Stroke: 178 mm (7.01 in)
- Collapsed length: 333.0 mm (13.11 in)
- Extended length: 20.12 in (511 mm)
- Body diameter: 2.00 in (50.8 mm)
- Bore: 1.18 in (30 mm)
- Dust shield diameter: 2.36 in (60 mm)
- Hydraulic stop: Yes
Used in this Meritor model
