The R005756R Meritor stud is a right hand thread wheel stud with a round head and drum shoulder, built to Grade 8. It measures 3-3/8 in. from under the head, with a 1.98 in. body length and a stepped body diameter of 0.808 in. and 0.786 in. Threads are 3/4"-16 UNF-2A, 16 threads per inch, with 1.00 in. of thread length and a 0.75 in. thread diameter. The serrated section is 0.820 in. in diameter by 0.50 in. long, and the drum shoulder measures 0.808 in. diameter by 0.31 in. long. Head diameter is 1.28 in. with a 0.31 in. head thickness. VMRS 018-003-009. Call us to confirm proper fit for your wheel end.
Interchanges:
- Budd 59066
This unit is sold in packs of 10.
Tech Specs
- Length from Under Head:3 3/8 in.
- Type:Headed w/Drum Shoulder
- Thread:3/4"-16
- Head Style:Round
- Grade:8
- Body Length:1.98 in.
- Thread Direction:RH
- Metric Thread Size:3/4-16 UNF-2A
- Serration:Serrated
- Body Diameter:0.808 in./0.786 in.
- Threads per Inch:16
- OEM:Budd 59066
- Serration Diameter:0.820 in.
- Thread Length:1.00 in.
- Serration Length:0.50 in.
- Head Thickness:0.31 in.
- Thread Diameter:0.75 in.
- Notes:Stepped Body Diameter
- VMRS Code:018-003-009
- Drum Shoulder Diameter:0.808 in.
- Drum Shoulder Length:0.31 in.
- Head Diameter:1.28 in.
Used in this Meritor model
