The Meritor tie rod end E-9877 or E9877 is a roadside-style steering end built to Meritor specifications. The large taper diameter measures 1.25 in. and the small taper diameter is 1.08 in., with a taper length of 1.36 in. The rod thread is 1.25 in. diameter, 12 threads per inch, right-hand direction. The stud thread is 0.875 in. diameter at 14 threads per inch, with a stud center to rod end measurement of 5.75 in. Lubrication is through a side-mounted zerk fitting. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Roadside style tie rod end
Large taper diameter: 1.25 in., small taper diameter: 1.08 in.
Taper length: 1.36 in.
Rod thread: 1.25 in. diameter, 12 TPI, right-hand
Stud thread: 0.875 in. diameter, 14 TPI
Stud center to rod end: 5.75 in., side zerk lubrication
Tech Specs
- Type: 1
- Style: Roadside
- Large Taper Diameter: 1.25 in.
- Small Taper Diameter: 1.08 in.
- Taper Length: 1.36 in.
- Rod Thread Diameter: 1.25 in.
- Rod Threads per Inch: 12
- Rod Thread Direction: Right-Hand (RH)
- Stud Thread Diameter: 0.875 in.
- Stud Threads per Inch: 14
- Stud Center to Rod End: 5.75 in.
- Lubrication: Side zerk fitting
