The Meritor E9590 or E-9590 is a camshaft enclosure tube from the Euclid brake and wheel-end line, designed to protect the S-cam shaft in drum brake assemblies. The tube measures 23.50 in. in overall length with a 1.875 in. outside diameter. Both the spider end and the support end share a 1.50 in. inside diameter, and the cam length this enclosure is matched to is 26.625 in. Call us to confirm proper fit for your axle and brake configuration before ordering.
Interchanges:
- Automann 11623161A
- Dayton Parts Batco 03148
- Hercules H3035
Features
Tube overall length: 23.50 in.
Tube outside diameter: 1.875 in.
Inside diameter at both spider end and support end: 1.50 in.
Matched to 26.625 in. cam length
Genuine Euclid part, cataloged under Meritor brake and wheel-end
Tech Specs
- Cam Length: 26.625 in.
- Inside Diameter-Spider End: 1.50 in.
- Inside Diameter-Support End: 1.50 in.
- Tube Outside Diameter: 1.875 in.
- Tube Overall Length: 23.50 in.
