The Midland Haldex EL13060X is a 1300 Series single-cylinder air compressor with a 4-hole base mount configuration. It features right-head and right-block rotation, a top-flange discharge, and a base oil feed option. Bore diameter is 2.75 in. with a 1.50 in. stroke, rated displacement of 13.0 CFM at 1250 RPM, and a maximum turbo-charge pressure of 35 PSI. The rotatable head allows adjustment before installation. Overall dimensions: 11.41 in. tall, 4.84 in. wide, 11.20 in. long, with a 2.14 in. external shaft length. The EL13060X corresponds to OEM part number N7006C. Call us to confirm proper fit for your application.
Interchanges:
- KN12040
- KN13000
- KN13060
- KN13060X
- Meritor R955EL13060X
A refundable core charge of $210.00 applies to this item and will be collected at checkout. The core charge is refunded upon receipt of your returned core, subject to its condition; customer is responsible for return shipping. Call us at (877) 776-4600 for details.
A factory handling fee of $25.00 per unit is added at checkout.
Features
1300 Series air compressor, 4-hole base mount, belt drive
Rated displacement: 13.0 CFM @ 1250 RPM
Bore diameter: 2.75 in., stroke: 1.50 in.
Max turbo-charge pressure: 35 PSI
Rotatable head and end cap for installation flexibility
Top-flange discharge, base oil feed option, water cooled
Tech Specs
- OEM Part Number: N7006C
- Head Rotation: Right
- Block Rotation: Right
- Discharge Type: Top / Flange
- Base Oil Feed Option: Yes
- Overall Height: 11.41 in.
- Overall Width: 4.84 in.
- Overall Length: 11.20 in.
- External Shaft Length: 2.14 in.
- Bore Diameter: 2.75 in.
- Stroke: 1.50 in.
- Max Turbo-Charge Pressure: 35 PSI
- Rated Displacement: 13.0 CFM @ 1250 RPM
- Core Group: 1301
- Drive Type: Belt Drive
- Cooling: Water Cooled
- Mount: 4-Hole Base
