Genuine Midland Haldex Aba Slack brake parts P/N: 40020235, expert help when you need it! Call us for any questions on this part or availability!
The gradual adjustment of the S-ABA lowers the risk of over-adjustment during prolonged braking.
Standard Steer Axle Application.
Features
S-ABA Brake Adjusteruster
High alloy steel gears.
Rolled wormshaft.
Heat-treated housing.
Centralized clutch.
For Standard Application.
Tech Specs
- Spline Diameter-Spline Count: 1-1/4"-10
- Arm Length: 5-1/2"
- Body Angle: 35°
- Offset: 0
- Arm Hole Diameter: 1/2"
- Bracket Kit: 42710576
- Anchor Bracket Style: Strap
- OEM Part Number: 409-26040
- Grease Fitting Location: 180°
- Grease Fitting Type: Straight
Additional Information
The clearance-sensing design maintains a constant and uniform distance between the brake drum and lining.The gradual adjustment of the S-ABA lowers the risk of over-adjustment during prolonged braking.
Standard Steer Axle Application.
