The Midland Haldex RDB109958CRX is an ADB22X disc brake caliper and carrier assembled unit for Freightliner applications. This is the left-hand side, radial carrier mounting configuration with a 12-degree brake chamber angle. The FMSI number is D1369. The kit ships as a complete caliper and carrier assembly, so no separate carrier sourcing is required. Dimensions on record are 11 in. x 19.5 in. x 15.5 in. (H x W x L). Note that the manufacturer has listed this part number as no longer available from the manufacturer through some distribution channels; confirm current availability by calling Pro Gear and Transmission directly before ordering.
Features
ADB22X disc brake caliper model
Left-hand (LH) side fitment
Radial carrier mounting configuration
12-degree brake chamber angle
FMSI number D1369
Supplied as caliper and carrier assembled, ready to install
Tech Specs
- Caliper Model ADB22X
- Side Left Hand (LH)
- Carrier Mounting Radial
- Brake Chamber Angle 12 Degrees
- FMSI Number D1369
- Application Freightliner
- Kit Contains Caliper and Carrier Assembled
- Dimensions (H x W x L) 11 in. x 19.5 in. x 15.5 in.
