The Midland Haldex 3558006X is a Model SS296C Super Single Cylinder air compressor designed for Cummins C-Series engine applications. It delivers 13.2 cubic feet per minute of displacement with a left-side air inlet and front-facing air outlet. The unit features an 11-tooth spline drive shaft, flange mounting, and a threaded discharge port. It is engine-driven and water-cooled, with a thru-drive configuration that accommodates a power steering pump in-line. The core group designation is CUM-4. Also referenced as part number EX3558006X. Call us to confirm proper fit for your specific engine and chassis configuration.
Include installation gaskets
A refundable core charge of $273.00 applies to this item and will be collected at checkout. The core charge is refunded upon receipt of your returned core, subject to its condition; customer is responsible for return shipping. Call us at (877) 776-4600 for details.
Features
Model SS296C Super Single Cylinder configuration
13.2 CFM displacement output
Left-side air inlet, front-facing air outlet
11-tooth spline engine drive, flange mount
Thru-drive design supports in-line power steering pump
Water-cooled, threaded discharge port, core group CUM-4
Tech Specs
- Model: SS296C Super Single Cylinder
- Cubic Feet Per Minute: 13.2
- Air Inlet: Left
- Air Outlet: Front
- Spline: 11 Tooth
- Drive Type: Engine Drive, Flange Mount
- Cooling: Water Cooled
- Discharge Type: Threaded
- Thru-Drive: Yes - for power steering pump
- Core Group: CUM-4
- Alternate Part Number: EX3558006X
Additional Information
Port orientation viewed from rearInclude installation gaskets
