The Haldex AL956116 is a Trailer Roll Stability (TRS) ECU Power Cable designed for Roll Stability System applications. It provides a Delphi 5-pin North American power connection and measures 0.5 meters in length, operating at 12V. Compatible with Haldex standard ABS wheel speed sensors, this cable is the basic TRS power configuration without brake light illumination benefit. To remove or insert this cable, slide the lock lever outward before disconnecting. Also referenced as AL956116M1D and OEM number 834005001. Call us to confirm compatibility with your specific TRS system before ordering.
Features
TRS ECU Power Cable for Trailer Roll Stability (TRS) applications
Delphi 5-pin North American power convention connector
Cable length: 0.5 meters
Operating voltage: 12V
Compatible with Haldex standard ABS wheel speed sensors
Lock lever must be slid outward to remove or insert the cable connector
Tech Specs
- Application: Trailer Roll Stability (TRS) systems
- Connector Type: Delphi 5-Pin North American Power Convention
- Cable Length: 0.5 meters
- Voltage: 12V
- Sensor Compatibility: Haldex Standard ABS Wheel Speed Sensors
- Configuration: Basic TRS power cable (without brake light illumination benefit)
- OEM Number: 834005001
- Also referenced as: AL956116M1D
