The Midland Haldex RC2077136X is a single-plate, push-type clutch pack designed for Caterpillar 3116 and 3126 engines. It pairs a RC3302077X cover assembly with a 3300092078 damp ceramic disc assembly. The flat flywheel mounting uses a 14.125 in. or 14.625 in. bolt circle, and the input shaft interface is a 1.5 in.-10 spline. Maximum rated torque is 500 ft-lb. The disc assembly is available in a non-remanufactured version, and the LP2077136 clutch number may also be used for this application. Call us to confirm proper fit for your specific engine and transmission combination.
This clutch pack includes a remanufactured cover assembly (RC3302077X) and a new disc assembly (3300092078).
Replacement disc assemblies are available in new only.
Core Group: LP3301.
A refundable core charge of $56.00 applies to this item and will be collected at checkout. The core charge is refunded upon receipt of your returned core, subject to its condition; customer is responsible for return shipping. Call us at (877) 776-4600 for details.
Features
Push-type, single-plate design for flat flywheel mounting
Damp ceramic disc assembly (P/N 3300092078) for consistent engagement
Cover assembly P/N RC3302077X included
Max. torque rating: 500 ft-lb
1.5 in.-10 spline input shaft interface
Bolt circle: 14.125 in. or 14.625 in. - fits CAT 3116 and 3126 engine applications
Tech Specs
- Cover Assembly RC3302077X
- Disc Assembly 3300092078
- Disc Type Damp Ceramic
- Max. Torque 500
- Bolt Circle 14.125 , 14.625
- Application CAT 3116 Engine, CAT 3126 Engine
- Core Group LP3301
- Approximate Weight 45 lbs.
Additional Information
New clutch number LP2077136 may also be used for this application.This clutch pack includes a remanufactured cover assembly (RC3302077X) and a new disc assembly (3300092078).
Replacement disc assemblies are available in new only.
Core Group: LP3301.
