The Midland Haldex APM69S6MXM16 is a male 90-degree swivel fitting elbow designed for heavy-duty air brake and pneumatic lines. It features a 6mm metric push-to-connect port with an M16 thread body and meets DOT push-fit standards. The 90-degree swivel design allows the air line to be routed at a right angle without kinking, making it suited for tight plumbing runs in brake system installations. Also referenced as MDAPM69S6MXM16 by some catalog sources. Sold individually by Pro Gear and Transmission. Call us to confirm proper fit for your specific brake or air system application.
Features
Male 90-degree swivel elbow configuration for right-angle air line routing
6mm metric push-to-connect port (DOT push-fit standard)
M16 thread body for secure chassis or component mounting
Swivel design allows line orientation adjustment after installation
Also cataloged as MDAPM69S6MXM16
Sold individually (unit of measure: each)
Tech Specs
- Part Number: APM69S6MXM16
- Alternate Part Number: MDAPM69S6MXM16
- Port Size: 6mm metric push-to-connect
- Thread Size: M16
- Fitting Angle: 90 degrees
- Swivel: Yes
- Compliance: DOT push-fit metric standard
- Unit of Measure: Each
