The Midland Haldex KN27010 is a height control valve designed to maintain consistent chassis ride height on air-suspended vehicles by inflating or deflating suspension bellows in proportion to load changes. Built from Engineering Grade Plastic (EGP), the valve features a horizontal arm with a maximum length of 8.2 inches that can be trimmed to suit the specific installation. All ports are 1/4" NPT. A single valve handles both left and right installations and can control two suspension bellows simultaneously. The high-flow design is recommended for tractor applications. Note: this unit ships without dump valve and linkage kit. Call us to confirm proper fit for your application.
For service parts: Exhaust Cover Repair Kit - part number RN10JE. Linkage Repair Kit - part number RN10JC.
Interchanges:
- 1671999C92
- 80-27010
- HDX-KN27010
- KN27010-MD
- MDKN27010
- N20404AA
- N20404CA
Features
Engineering Grade Plastic (EGP) body construction
Horizontal arm adjustable up to 8.2" maximum - cut to desired length for application
All ports: 1/4" NPT
One valve serves both left-hand and right-hand installations
Controls two suspension bellows from a single valve
High-flow design recommended for tractor applications
Supplied without dump valve and linkage kit
Tech Specs
- Horizontal Arm Length: 8.2" (Max)
- All Ports: 1/4" NPT
- Notes: Without dump valve and linkage kit included
Additional Information
Variations in chassis height resulting from different load conditions are equalized by inflating or deflating the air suspension bellows in proportion to the load carried. This valve uses a special Navistar-style design with no vertical link arm; the horizontal arm is adjusted and cut to the desired length for each installation.For service parts: Exhaust Cover Repair Kit - part number RN10JE. Linkage Repair Kit - part number RN10JC.
