The Midland Haldex GG4707QJ is a New Gripper brake shoe kit for 16-1/2 in. x 7 in. S-cam air brakes, built to FMSI 4707 with shoe ID Q. The boxed kit contains two shoes and the CQ66867 hardware kit, with extended wear lining in 2020 grade friction material, friction code FF, and standard cam and hardware. It carries a 23,000 lb GAWR. A drum brake shoe kit supplies the friction surfaces: the lined shoes press against the drum to slow the wheel. Call us to confirm proper fit for your axle.
Uses extended wear lining, standard cam and hardware.
A factory handling fee of $25.00 per order is added at checkout.
Features
Two shoes plus hardware kit CQ66867, boxed
16-1/2 in. x 7 in. S-cam brake, FMSI 4707, shoe ID Q
2020 grade extended wear lining, friction code FF
Standard cam and hardware
Lining provides the friction surface that slows the wheel against the drum
Tech Specs
- Width: 7 in.
- Shoe size: 16-1/2 in. x 7 in.
- FMSI number: 4707
- Shoe ID: Q
- Hardware kit: CQ66867
- Includes hardware kit: Yes
- Core group: 4707
- Material type: 2020
- Friction code: FF
- Brake type: S-cam
Additional Information
Contains two new shoes and hardware kit.Uses extended wear lining, standard cam and hardware.
