EL16312X Midland Haldex Compressor

The Midland Haldex EL16312X is a gear driven, flange mount air compressor with a water cooled head and a top threaded discharge. Oil feeds through the end cap and drains through the flange. It has a 2.75 in. bore, measures 12.19 in. high, 7.10 in. wide and 9.90 in. long, and is set up with right head rotation and right block rotation for 60-Series, DDC 0° tilt applications. It is a thru-drive, adapterless unit. A genuine Midland Haldex part from Pro Gear and Transmission. Call us to confirm proper fit.

A refundable core charge of $210.00 applies to this item and will be collected at checkout. The core charge is refunded upon receipt of your returned core, subject to its condition; customer is responsible for return shipping. Call us at (877) 776-4600 for details.

A factory handling fee of $25.00 per order is added at checkout.

Features

Flange mount, gear drive, water cooled
Top threaded discharge, end cap oil feed, flange oil drain
Right head rotation and right block rotation
Thru-drive, adapterless
2.75 in. bore, 12.19 in. overall height, 7.10 in. overall width, 9.90 in. overall length
Application: 60-Series, DDC 0° tilt

Tech Specs

• Head Rotation Right
• Block Rotation Right
• Application 60-Series , DDC 0° Tilt
• Notes Thru-Drive , Adapterless
• OEM Part Number NT7231
• Core Group 1631
• Overall Height 12.00 in. (EL1300), 12.19 in. (EL1600)
• Overall Width 7.10 in.
• Overall Length 9.90 in.
• Bore Diameter 2.75 in.
• Stroke 1.50 in. (EL1300) and 1.87 in. (EL1600)
• Rated Displacement 13.0 (EL1300) and 16.1 (EL1600) CFM @ 1250 RPM
• Approximate Weight 75 lbs.

Additional Information

Orientation viewed from front.
Service Units are furnished without governors and manifolds and may require head rotation and end cap rotation before installation or changeover.
Thru drive units must not exceed 65 ft. lbs. of transmitted torque.
Torque Nut to 220-255 ft. lbs.
Include installation gaskets.
