The Midland Haldex 3018543X is an SS296 Super Single Cylinder air brake compressor designed for Cummins L, K, and N series engines. It delivers 13.2 cubic feet per minute of air flow and features a left-side air inlet, rear air outlet, and a left-side direct unloader port. The compressor uses a flange mount configuration, is engine-driven, and is water-cooled. Core Group CUM-1. Cross-reference numbers for this unit include 3044389X, AR3000174, AR3045670, AR3045671, AR3045672, AR3045673, AR3559509, AR3559511, AR73308, AR73350, AR73351, AR73352, and AR73353. A genuine Midland Haldex part sold by Pro Gear and Transmission. Call us to confirm proper fit for your engine and chassis application.
Port orientation is viewed from the rear of the unit.
Compressors EL13040 and EL13040X may also be used for this application.
Installation gaskets are included with this part.
Cross-reference numbers: 3044389X, AR3000174, AR3045670, AR3045671, AR3045672, AR3045673, AR3559509, AR3559511, AR73308, AR73350, AR73351, AR73352, AR73353, GK8543, UK8543.
A refundable core charge of $140.00 applies to this item and will be collected at checkout. The core charge is refunded upon receipt of your returned core, subject to its condition; customer is responsible for return shipping. Call us at (877) 776-4600 for details.
Features
SS296 Super Single Cylinder compressor, 13.2 CFM rated output
Air inlet: left side; air outlet: rear; unloader port: left, direct type
Flange mount, engine-driven, water-cooled design
Application: Cummins L, K, and N series engines (Core Group CUM-1)
Cross-references: 3044389X, AR3000174, AR73308, AR73350, and additional AR-series numbers
Installation gaskets included; CoreFree option available as P/N 3018543RX
Tech Specs
- Model: SS296 Super Single Cylinder
- Cubic Feet Per Minute: 13.2
- Air Inlet: Left
- Air Outlet: Rear
- Unloader Port: Left, Direct
- Mount Type: Flange Mount
- Drive: Engine Drive
- Cooling: Water Cooled
- Application: Cummins L, K, and N series engines
- Core Group: CUM-1
Additional Information
A CoreFree version of this compressor is available as part number 3018543RX.Port orientation is viewed from the rear of the unit.
Compressors EL13040 and EL13040X may also be used for this application.
Installation gaskets are included with this part.
Cross-reference numbers: 3044389X, AR3000174, AR3045670, AR3045671, AR3045672, AR3045673, AR3559509, AR3559511, AR73308, AR73350, AR73351, AR73352, AR73353, GK8543, UK8543.
