Genuine Midland Haldex A Slack brake parts P/N: 40020211, for more precise availability please give us a call and we will help you out!
The gradual adjustment of the S-ABA lowers the risk of over-adjustment during prolonged braking.
For 16-1/2" Brake Assembly, Trailer Axle Application.
Can be used for 40010211.
Features
S-ABA Brake Adjusteruster
High alloy steel gears
Rolled wormshaft
Heat-treated housing
Centralized clutch
Tech Specs
- Spline Diameter-Spline Count: 1-1/2"-28
- Arm Length: 5-1/2"
- Body Angle: 0°
- Offset: 0
- Arm Hole Diameter: 1/2"
- Bracket Kit: 42710563
- Anchor Bracket Style: Plate & Flat Stud
- OEM Part Number: 409-26002
- Grease Fitting Location: 180°
- Grease Fitting Type: Straight
Additional Information
The clearance-sensing design maintains a constant and uniform distance between the brake drum and lining.The gradual adjustment of the S-ABA lowers the risk of over-adjustment during prolonged braking.
For 16-1/2" Brake Assembly, Trailer Axle Application.
Can be used for 40010211.
