The Midland Haldex SC24XLCW is a Size T24 service brake chamber with a welded clevis and extra long stroke, delivering 3.00 inches (76mm) of available stroke. The steel pressure housing is powder coated and features resistance-welded air ports threaded 3/8-18 NPTF, rated to a maximum of 150 psi. The flat-bottom service housing is built from 10-gauge steel with a powder-coated finish for corrosion resistance. A World Class diaphragm compound maintains flexibility down to -40°F. The Orange Alert stroke indicator and self-piloting dust shield are included. Stud spacing (dimension E) is 4.75 inches (120.7mm) with 5/8-11 UNC studs, and the clevis pin centerline sits 2.25 inches from the face of the service housing. Call us to confirm proper fit for your application.
A = Length from mounting bracket to end of Spring Housing: 4.3 in. (109mm)
D = Dimension at Service Clampband: 7.5 in. (191mm)
E = Stud Spacing: 4.75 in. (120.7mm) with 5/8-11 UNC studs
J = Pushrod length from face of Service Housing: 1.00 in.; 5/8-18 UNF pushrod threads
K = Distance to Clevis Pin centerline from face of Service Housing: 2.25 in.
T = Air port position: 0°
Cross-references: K058753, BW K058753, HDX-SC24XLCW, MIDSC24XLCW, BSC24LSWC, 2602436C91, 3682379C91, 127240030. Additional interchange numbers may apply; call us to verify the correct part for your brake system.
Features
Size T24 service chamber with welded clevis, extra long stroke
Available stroke: 3.00 inches (76mm)
Maximum air pressure: 150 psi
Air port threads: 3/8-18 NPTF
Stud spacing (E): 4.75 inches (120.7mm) with 5/8-11 UNC studs
Orange Alert stroke indicator and self-piloting dust shield included
Tech Specs
- Actuator Type Size: 24
- Stroke Type: Extra Long
- Available Stroke: 3.00 in. (76mm)
- A - Length from mounting bracket face: 4.3 in. (109mm)
- D - Dimension at Service Clampband: 7.5 in. (191mm)
- E - Stud Spacing: 4.75 in. (120.7mm), 5/8-11 UNC studs
- J - Pushrod Length from face of Service Housing: 1.00 in., 5/8-18 UNF pushrod threads
- K - Distance to Clevis Pin centerline from face of Service Housing: 2.25 in.
- Air Port Threads: 3/8-18 NPTF
- Maximum Air Pressure: 150 psi
- Service Housing Material: 10-gauge steel, powder coated
- Pressure Housing: Steel, powder coated, resistance-welded air ports
- Diaphragm: High-quality rubber compound, rated to -40°F
- Quantity: 1
Additional Information
Dimensional key for SC24XLCW:A = Length from mounting bracket to end of Spring Housing: 4.3 in. (109mm)
D = Dimension at Service Clampband: 7.5 in. (191mm)
E = Stud Spacing: 4.75 in. (120.7mm) with 5/8-11 UNC studs
J = Pushrod length from face of Service Housing: 1.00 in.; 5/8-18 UNF pushrod threads
K = Distance to Clevis Pin centerline from face of Service Housing: 2.25 in.
T = Air port position: 0°
Cross-references: K058753, BW K058753, HDX-SC24XLCW, MIDSC24XLCW, BSC24LSWC, 2602436C91, 3682379C91, 127240030. Additional interchange numbers may apply; call us to verify the correct part for your brake system.
