The Muncie 49TA6088 is an EX Drive shaft extension housing designed for the XD10 configuration with an SAE output. Per Muncie's own service-parts document SP16-02_EX_Drive.pdf, this housing measures 24.12 inches overall length and is specified for cooler versions of the EX Drive assembly. The EX Drive system is built for use with Allison 3000 and 4000 series transmissions equipped with a retarder or rear-mounted cooler, allowing large gear or piston pumps to be direct-mounted without a separate driveline installation. The steel housing uses a wet spline design for extended spline durability. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your specific transmission and PTO configuration.
Features
SAE output configuration, XD10 designation
24.12" overall length (OAL) per Muncie service document SP16-02_EX_Drive.pdf
Specified for cooler versions of the EX Drive assembly
Steel housing construction with wet spline design for enhanced spline durability
Compatible with Allison 3000 and 4000 series transmissions with retarder or rear-mounted cooler
Supports direct mounting of large gear or piston pumps, eliminating separate driveline installation
Tech Specs
- Overall Length (OAL): 24.12 in.
- Output Type: SAE
- Configuration: XD10
- Application: Cooler versions of the Muncie EX Drive assembly
- Compatible Transmissions: Allison 3000 and 4000 series with retarder or rear-mounted cooler
- Housing Material: Steel
- Spline Design: Wet spline
