The Muncie 828S-M6513-Q3EG or 828SM6513Q3EG is a heavy-duty power take-off from Muncie's 82 Series, engineered for high-torque and high-demand hydraulic and mechanical drive applications. The 82 Series features a cast iron housing, double-acting air shift for positive engagement and disengagement, and a rotatable direct-mount pump flange as standard. The series supports up to 500 lb.ft. intermittent torque and 95 HP at 1,000 RPM, making it suited for high-volume pumps and high-CFM blowers. Seven direct-mount pump options include SAE "B," "BB," "C," and "D" as well as DIN 5462 mounts, with two companion flange output types for remote pump or mechanical drive configurations. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Muncie 82 Series PTO, part number 828S-M6513-Q3EG or 828SM6513Q3EG
Double-acting air shift for positive engagement and disengagement
Cast iron housing construction
Up to 500 lb.ft. intermittent torque and 95 HP at 1,000 RPM (series rating)
Seven direct-mount pump options: SAE B, BB, C, D and DIN 5462 mounts
Rotatable direct-mount pump flange standard; two companion flange output types available
Tech Specs
- Series: Muncie 82 Series Power Take-Off
- Part Number: 828S-M6513-Q3EG or 828SM6513Q3EG
- Housing: Cast iron
- Shift type: Double-acting air shift
- Intermittent torque (series): Up to 500 lb.ft. at 1,000 RPM
- Continuous torque (series): Up to 350 lb.ft.
- Intermittent HP (series): Up to 95 HP at 1,000 RPM
- Pump mount options: SAE B, BB, C, D; DIN 5462
- Output types: Two companion flange output types
- Rotatable pump flange: Standard
- Assembly arrangements: 2
- Available speed ratios: 8
- Available output shaft options: 9
