NTN 423060C3 is a double row tapered roller bearing with a cone and cup design, built from through hardened steel. It has a 300 mm bore (ID), a 460 mm outside diameter (OD), a 148 mm cone width and a 118 mm cup width. The dynamic load rating is 1,610,000 N. A double row tapered bearing takes heavy radial load plus thrust in both axial directions, so a single unit can locate a shaft against push from either side in a heavy-duty rotating assembly. A genuine NTN part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Double row cone and cup design
Through hardened steel construction
300 mm bore (ID) and 460 mm outside diameter (OD)
148 mm cone width, 118 mm cup width
Dynamic load rating of 1,610,000 N
Takes radial load and thrust in both axial directions
Tech Specs
- Bore (ID): 300.000 mm
- Outside Diameter (OD): 460.000 mm
- Cone Width: 148.000 mm
- Cup Width: 118.000 mm
- Dynamic Load Rating: 1,610,000 N
- Construction: Through Hardened Steel
- Configuration: Double Row
