The NTN 32005VC12 is a single row tapered roller bearing cone and cup set built from through hardened steel. It measures 25 mm bore (ID) by 47 mm outside diameter, with a 15 mm cone width and an 11.5 mm cup width. The set carries a dynamic load rating of 28,500 N, making it suited to applications requiring a compact 25 mm bore tapered bearing assembly. Sold as a matched cone and cup pair by Pro Gear and Transmission.
Features
25 mm bore (ID)
47 mm outside diameter (OD)
15 mm cone width, 11.5 mm cup width
Single row tapered roller design
Through hardened steel construction
Dynamic load rating: 28,500 N
Tech Specs
- Bore (ID): 25 mm
- Outside diameter (OD): 47.000 mm
- Cone width: 15.000 mm
- Cup width: 11.500 mm
- Dynamic load rating: 28,500 N
- Design: Single row tapered roller
- Material: Through hardened steel
