This transmission rebuild package, made by PAI, is built around a full synchronizer assembly and its support hardware to restore clash-free gear engagement in a manual transmission. The kit includes a low range hub, a compound gear, a synchronizer assembly with sub-assembly, two housings, three support sleeves, a synchronizer clutch with two sets of eight discs, plus the pins, spring sleeves, clamps, and screws needed to complete the job. Everything for rebuilding the synchronizer section is packaged together as a single sell unit of one each.
Features
Low range hub (OEM 84KC410)
Compound gear (OEM 764KB4279)
Synchronizer assembly and sub-assembly (OEM 320KB464)
Two synchronizer housings (OEM 53KC486E)
Three synchronizer support sleeves (OEM 301KC243C)
Synchronizer clutch (OEM 21636360) with two sets of eight synchronizer discs (OEM 495KB361 and 495KB367)
Includes clamps, screws, pins, and spring sleeves to complete the rebuild
Tech Specs
- Sell pack: 1 EACH
- Kit contains: 1x low range hub, 1x compound gear, 1x synchronizer assembly, 1x synchronizer sub-assembly, 2x housing, 3x synchronizer support sleeve, 3x screw, 3x clamp (298KB213), 3x clamp (298KB214), 3x synchronizer pin (301KC33), 3x synchronizer pin (301KC34), 3x spring sleeve (107KD247), 3x spring sleeve (301KC35), 1x synchronizer clutch, 8x synchronizer disc (495KB361), 8x synchronizer disc (495KB367)
Additional Information
This upgrade kit consolidates the full synchronizer rebuild into one part number, cross-referencing to OEM numbers 84KC410, 764KB4279, 320KB464, 53KC486E, 301KC243C, 6AX1606X, 298KB213, 298KB214, 301KC33, 301KC34, 107KD247, 301KC35, 21636360, 495KB361, and 495KB367.Used in these Mack model
