This trunnion rebuild kit fits Mack trucks with the 46,000 camel back suspension and is made by PAI. It bundles thrust washers, seals, washers, trunnion nuts, clamp spacers, a trunnion retainer, and the screws and nuts needed to rebuild the trunnion assembly. The kit is sold complete as one unit (1 each), giving the hardware to restore proper pivot geometry at the suspension trunnion.
Features
Complete trunnion rebuild kit for Mack 46,000 camel back suspension
Includes 4 thrust washers (FTW-4476)
Includes 2 seals (FOS-4451)
Includes 2 washers (FTW-4479)
Includes 2 trunnion nuts (FNU-4743) and 2 trunnion retainers (FCL-4713)
Includes clamp spacers, screws, and nuts to complete the assembly
Tech Specs
- Fitment: All Mack 46,000 camel back suspension
- Sell pack: 1 EACH
- Kit contents: Thrust Washer (FTW-4476) x4, Seal (FOS-4451) x2, Washer (FTW-4479) x2, Trunnion Nut (FNU-4743) x2, Screw (FSC-0137) x2, Nut (FNU-0209) x2, Clamp Spacer (FSP-4788) x2, Clamp Spacer (FSP-4787) x2, Trunnion Retainer (FCL-4713) x2, Screw (ESC-1610) x8
