The Wabco 4725002230 is a tractor ABS/ATC valve package that consolidates a service brake relay valve, two ABS modulator valves, and one ATC valve into a single unit, eliminating the need for separate valve installation. Designed for D and E Version ECUs only, it operates at 12V with a bayonet connector and a 5.5 psi crack pressure. Replacement kits include a replacement valve, mounting bolts, O-rings, and lubricant. Call us to confirm proper fit for your application.
Interchanges:
- 223
- 472
- 500
- Automann 170S4725002230
- Bepco 4725002230X
Features
Combines service brake relay valve, two ABS modulator valves, and one ATC valve in one package
Designed for D and E Version ECUs only
12V operating voltage with bayonet connector
5.5 psi crack pressure
Replacement kits include valve, bolts, O-rings, and lubricant
Tech Specs
- Application: Combines a service brake relay valve, two ABS modulator valves, and one ATC valve - eliminates separate valve installation
- Compatible ECUs: D and E Version ECUs only
- Voltage: 12V
- Connector Type: Bayonet
- Crack Pressure: 5.5 psi
- Valve Replaced: Entire valve package
- Part Number: 4725002230 or 472 500 223 0
- Replacement Kit Contents: Replacement valve, bolts, O-rings, and lubricant
